Need help with SunPro Super Tach II - Vintage Mustang Simply, green wire to neg side of coil, red to a switched power source and black to a ground. Could simply be a bad tach. I say this because I just bought on of those mini Sunpro Super tachs to put in a vintage car. I pulled the case apart and installed it in behind the vintage tach face. It runs really irratic about 70% of the time. Sunpro® 3 3/8 Inch Retro Tachometer 8000 Rpm (Fz88r) This 3-3/8 inch all-metal Sunpro® tachometer has a black face with 0 to 8,000 RPM range. Reproduced '60s styling with modern electronics inside. Features include: • internal settings for 1-, 2-, 4-, 6-, 8-, and 10-cylinder engines. • all-metal housing with removable chrome cup. • brackets for mounting either to steering column or dash.
