The electrical current which runs through the wiring of your Nissan Xterra can be compared to blood, that's flowing through the veins of a human body. Fuses are those very components that stand on guard of your SUV's electrical system while protecting it from possible damage caused in case of a short circuit. These components are designed to withstand the required level of electrical current.

To release the cover on the smaller fuse box, gently pull out the two retaining clips. Pull off the fuse box cover and turn it over to view the fuse location diagram. There is also another fuse location diagram in your owner's manual. To release the cover on the larger fuse box, gently push in the two tabs to release the retaining clips.
